L-Acoustics LA4 User Manual

Constant Curvature WST systems presets
ARCS II
preset(s)
loudspeaker
conguration
ARCS II KS28 or SB28*
acoustic properties
line source [ARCS II] — 50 Hz - 20 kHz
line source + subwoofer [ARCS II] [xx28_60]
down to 25 Hz
reinforced LF contour
* with subwoofers as a cardioid array, use [xx28_60_C] or [xx28_60_Cx]
[ARCS II]
loudspeaker elements outputs channels routing gain delay polarity mute
LF OUT 1 LF ON
HF OUT 2 HF
IN A 0 dB 0 ms +
ON
LF OUT 3 LF ON
HF OUT 4 HF
IN A 0 dB 0 ms +
ON
Routing, gain, delay, polarity and mute parameters can be modied by the user.
52 Preset Guide owner's manual (EN) version 16.0
