Variable Curvature WST systems presets
Kudo
preset(s)
loudspeaker
conguration
Kudo
KS28 or SB28
or SB18 *
acoustic properties
[KUDOxx_25] 35 Hz - 20 kHz
[KUDOxx_40] 40 Hz - 20 kHzline source
[KUDOxx_60]
—
60 Hz - 20 kHz
line source +
subwoofer
[KUDOxx_40] [xxx8_60]
down to 25 Hz (KS28 and
SB28) or 32 Hz (SB18)
reinforced LF contour
* with subwoofers as a cardioid array, use [xxx8_60_C] or [xxx8_60_Cx]
K-LOUVER and presets
Always ensure that the K-LOUVER panels are set in accordance with the selected preset:
[KUDO50_xx]: 50º, [KUDO80_xx]: 80º, [KUDO110_xx]: 110º
Refer to the Kudo user manual for details.
[KUDOxx_xx]
loudspeaker elements outputs channels routing gain delay polarity mute
left LF OUT 1 LF ON
right LF OUT 2 LF ON
MF OUT 3 MF ON
HF OUT 4 HF
IN A 0 dB 0 ms +
ON
left/right when looking at the front face of the enclosure
Routing, gain, delay, polarity and mute parameters can be modied by the user.
44 Preset Guide owner's manual (EN) version 16.0
