Coaxial loudspeaker enclosures presets
The factory presets dedicated to coaxial enclosures are optimized for short throw applications. In the following sections,
tables describe the loudspeaker congurations and the factory presets for each system. Discriminant acoustic properties
of each loudspeaker conguration are given, such as -10 dB bandwidth or LF limit, or frequency response contour.
X4i
X4i is a passive coaxial loudspeaker enclosure.
preset(s)
loudspeaker
conguration
X4i Syva Sub
acoustic properties
X4i [X4] — 120 Hz - 20 kHz
X4i + Syva Sub [X4] [SYVA SUB_200]
down to 29 Hz
reinforced LF contour
[X4]
outputs channels routing gain delay polarity mute
OUT 1 PA IN A 0 dB 0 ms + ON
OUT 2 PA IN A 0 dB 0 ms + ON
OUT 3 PA IN B 0 dB 0 ms + ON
OUT 4 PA IN B 0 dB 0 ms + ON
Routing, gain, delay, polarity and mute parameters can be modied by the user.
56 Preset Guide owner's manual (EN) version 16.0
