Coaxial loudspeaker enclosures presets
5XT
5XT is a passive coaxial loudspeaker enclosure.
preset(s)
loudspeaker
conguration
5XT SB15m*
acoustic properties
5XT [5XT] — 95 Hz - 20 kHz
5XT + SB15m [5XT] [SB15_100]
down to 40 Hz
reinforced LF contour
* with subwoofers as a cardioid array, use [SB15_100_C] or [SB15_100_Cx]
[5XT]
outputs channels routing gain delay polarity mute
OUT 1 PA IN A 0 dB 0 ms + ON
OUT 2 PA IN A 0 dB 0 ms + ON
OUT 3 PA IN B 0 dB 0 ms + ON
OUT 4 PA IN B 0 dB 0 ms + ON
Routing, gain, delay, polarity and mute parameters can be modied by the user.
Preset Guide owner's manual (EN) version 16.0 57
