L-Acoustics LA4 User Manual

Variable Curvature WST systems presets
Kiva SB15m
preset(s)
loudspeaker
conguration
Kiva SB15m*
acoustic properties
line source [KIVA] — 80 Hz - 20 kHz
[KIVA_SB15]line source +
coupled subwoofer
[KIVA] [SB15_100]
down to 40 Hz
reinforced LF contour
single or pair of enclosures
[KIVA_FI]
—
80 Hz - 20 kHz
at response
pair of enclosures +
coupled subwoofer
[KIVA_FI]
[SB15_100]
down to 40 Hz
reinforced LF contour
* with subwoofers as a cardioid array, use [SB15_100_C] or [SB15_100_Cx]
[KIVA]
outputs channels routing gain delay polarity mute
OUT 1 PA IN A 0 dB 0 ms + ON
OUT 2 PA IN A 0 dB 0 ms + ON
OUT 3 PA IN A 0 dB 0 ms + ON
OUT 4 PA IN A 0 dB 0 ms + ON
[KIVA_FI]
outputs channels routing gain delay polarity mute
OUT 1 PA IN A 0 dB 0 ms + ON
OUT 2 PA IN A 0 dB 0 ms + ON
OUT 3 PA IN B 0 dB 0 ms + ON
OUT 4 PA IN B 0 dB 0 ms + ON
[KIVA_SB15]
loudspeaker elements outputs channels routing gain delay polarity mute
SB15m OUT 1 LF ON
KIVA OUT 2 PA ON
KIVA OUT 3 PA ON
KIVA OUT 4 PA
IN A 0 dB 0 ms +
ON
Hybrid preset combining [KIVA] with [SB15_100], pre-alignment delay included.
Routing, gain, delay, polarity and mute parameters can be modied by the user.
Preset Guide owner's manual (EN) version 16.0 41
