Colinear systems presets
Colinear systems presets
The factory presets dedicated to colinear sources are optimized for medium throw applications.
In the following sections, tables describe the loudspeaker congurations and the factory presets for each system.
Discriminant acoustic properties of each loudspeaker conguration are given, such as -10 dB bandwidth or LF limit, or
frequency response contour.
Syva
preset(s)
loudspeaker
conguration
Syva Syva Low Syva Sub
acoustic properties
colinear source [SYVA] — — 87 Hz - 20 kHz
colinear source +
coupled Syva Low
[SYVA LOW SYVA] —
colinear source +
separated Syva Low
[SYVA] [SYVA LOW_100] —
down to 40 Hz
reinforced LF contour
colinear source
+ coupled Syva Low
+ Syva Sub
[SYVA LOW SYVA] [SYVA SUB_100]
colinear source
+ separated Syva Low
+ Syva Sub
[SYVA] [SYVA LOW_100] [SYVA SUB_100]
down to 27 Hz
reinforced LF contour
No pre-alignment delay values are required for the Syva system.
[SYVA]
outputs channels routing gain delay polarity mute
OUT 1 PA IN A 0 dB 0 ms + ON
OUT 2 PA IN A 0 dB 0 ms + ON
OUT 3 PA IN A 0 dB 0 ms + ON
OUT 4 PA IN A 0 dB 0 ms + ON
[SYVA LOW SYVA]
loudspeaker elements outputs channels routing gain delay polarity mute
Syva Low OUT 1 LF ON
Syva OUT 2 PA
IN A 0 dB 0 ms +
ON
Syva Low OUT 3 LF ON
Syva OUT 4 PA
IN B 0 dB 0 ms +
ON
Hybrid preset combining Syva and Syva Low.
Use only with AutoConnect or when Syva and Syva Low are within 60 cm (24 in) from each other, that is,
acoustically coupled.
When Syva and Syva Low are more than 60 cm (24 in) apart, create a custom preset in LA Network Manager
combining [SYVA] and [SYVA LOW_100].
54 Preset Guide owner's manual (EN) version 16.0
