Constant Curvature WST systems presets
Constant Curvature WST systems presets
The factory presets dedicated to constant curvature WST line sources are optimized for medium throw applications.
In the following sections, tables describe the loudspeaker congurations and the factory presets for each system.
Discriminant acoustic properties of each loudspeaker conguration are given, such as -10 dB bandwidth or LF limit, or
frequency response contour.
ARCS Wide / ARCS Focus
preset(s)
loudspeaker
conguration
ARCS Wide /
ARCS Focus
SB18*
acoustic properties
line source
[ARCS_WIFO] — 55 Hz - 20 kHz
line source + SB18 [ARCS_WIFO] [SB18_60]
down to 32 Hz
reinforced LF contour
single enclosure [ARCS_WIFO_FI] —
55 Hz - 20 kHz
at response
single enclosure + SB18m [ARCS_WIFO_FI] [SB18_60]
down to 32 Hz
reinforced LF contour
* with subwoofers as a cardioid array, use [SB18_60_C] or [SB18_60_Cx]
[ARCS_WIFO]
outputs channels routing gain delay polarity mute
OUT 1 PA IN A 0 dB 0 ms + ON
OUT 2 PA IN A 0 dB 0 ms + ON
OUT 3 PA IN A 0 dB 0 ms + ON
OUT 4 PA IN A 0 dB 0 ms + ON
[ARCS_WIFO_FI]
outputs channels routing gain delay polarity mute
OUT 1 PA IN A 0 dB 0 ms + ON
OUT 2 PA IN A 0 dB 0 ms + ON
OUT 3 PA IN B 0 dB 0 ms + ON
OUT 4 PA IN B 0 dB 0 ms + ON
Routing, gain, delay, polarity and mute parameters can be modied by the user.
