56
FMS
Commissioning
O
regulation
2
Operator
controls and
display
Calling up O
regulation
-
Switch display to
O
regulation.
22
text messages
Selector switch (1)
to "Status”.
Channel key 3
(4) upwards.
-
Call
up text messages
by pressing the
Acceptance key (3).
-
Back
Z
press the
Acceptance key (3)
again,
or turn selector
switch (1) to a different
position.
x
x
x
LAMTEC
LAMTEC
x
x
x
x
x
x
x
x
x
4
3
1
O2
-
regulation
active
55
57
