8: Line and Tunnel Settings
EDS1100/2100 Device Server User Guide 62
Host List Promotion
This feature allows Host IP promotion of individual hosts in the overall sequence.
To promote a specific Host:
1. Click the icon in the desired Host field, for example Host 2 and Host 3.
2. The selected Host(s) exchanges its place with the Host above it.
3. Click Submit. The hosts change sequence.
Tunnel – Disconnect Mode
Relates to the disconnection of a specific tunnel. Disconnect Mode ends Accept Mode and
Connect Mode connections. When disconnecting, the EDS1100/2100 unit shuts down the specific
tunnel connection gracefully.
The following settings end a specific tunnel connection:
The EDS1100/2100 receives the stop character.
The timeout period has elapsed and no activity is going in or out of the EDS1100/2100 device.
Both Accept Mode and Connect Mode must be idle for the time frame.
The EDS1100/2100 unit observes the modem control inactive setting.
Note: To clear data out of the serial buffers upon a disconnect, enable “Flush Serial Data”.
To configure the Disconnect Mode for a specific tunnel:
1. Select Tunnel on the menu bar, if you are not already in the Tunnel web page.
2. Select a tunnel number at the top of the page.
3. Select Disconnect Mode. The specific tunnel Disconnect Mode page appears.
Figure 8-18 Tunnel 1 Disconnect Mode
4. Enter or modify the following settings:
