1. Weights and dimensions
It is important to know the weight of the breaker for proper selection of handling equipment.
DMX
3
-1600
Dimensions - xed version 3P (mm)
Width 254
Depth 203
Height 321
Dimensions - fixed version 4P
Width 324
Depth 203
Height 321
Dimensions - draw-out version 3P*
Width 282
Depth 306
Height 352
Dimensions - draw-out version 4P*
Width 352
Depth 306
Height 352
Poles
Circuit breakers
Switch
disconnectors
Net
weight
Gross
weight
Net
weight
Gross
weight
Fixed
3P 16 kg 24 kg 14 kg 22 kg
4P 21 kg 30 kg 18 kg 27 kg
Draw-out*
3P 38 kg 46 kg 36 kg 44 kg
4P 51 kg 60 kg 48 kg 57 kg
Mobile Part
3P 21 kg 29 kg 19 kg 27 kg
4P 24 kg 33 kg 21 kg 30 kg
* Mobile part plus D/O base
