10.1. Installation of breaker DMX
3
fixed version
Mounting details
A = Fixing
point on plate
of enclosure
MIN 115
MIN 115321
321
307
324
100
MIN 66
236
254
ACTIVE POLE ACTIVE POLE
3P version
Fixed version
4P version
