7.7.2 Surface Recording
This menu is used to y a mission. A mission automatically records data of a
predened surface.
If the battery life does not last for the whole surface scan, divide the surface
into more than one individually planned surfaces.
Currently, a surface scan stopped due to low batteries, cannot be resumed.
a
23826_002_en
c d e
f kg h
b
ij
l
a Hamburger menu. Refer to 7.6
Hamburger Menu for details
b
Status bar. Refer to 7.4 Status
Bar for details.
c NOTIFICATIONS and/or Flight
Restrictions
d Emergency off switch
e Add a new scan
f Switch between different views
g Cancel surface scan planning
h Start surface scan mission
i Represents the scan pattern A.
Tap to edit
j Tap to open the surface scan
editor for scan pattern A again
k Add another scan pattern. Simply
drag and drop scan patterns A, B,
… to reorder them
l Return to launch button
Overview
Description of the Application, Mission Planning 79
