66
Version 2.0, Revision I
Cleaning and Maintenance
6
Replacement plate
1
2
Fig. 56
8. Reinsert the replacement plate (→ "Fig. 56-1").
Caution
The replacement plate must be completely dry.
9. When the cleaning process is finished, press any key of the control panel to confirm.
10. The print head moves back to the rest position; the message 15 disappears from the display.
The printer is once again ready for printing.
Warning
If no button is pressed to acknowledge the end of the cleaning procedure, the print head will be
closed automatically after a few minutes to prevent it from drying out.
However, the message 15 remains on the display, as the instrument assumes that the cleaning has
not been carried out.
6.3 Exchanging the cartridge
Note
The ink cartridge has to be replaced after 3.5 months at the latest or after 60,000 prints. On the white
surface on the front side of the ink cartridge, note the date when the ink cartridge was installed.
