1130 Backup battery
For access, remove these FRUs in order:
v “1010 Battery pack” on page 80
v “1030 Optical drive or travel cover” on page 84
v “1110 Palm rest assembly with cables” on page 98
DANGER
Use only the battery specified in the parts list for your computer. Any other
battery could ignite or explode.
Table 22. Removal steps of backup battery
2
1
When installing: Make sure that the battery connector is attached firmly to the
system board.
Removing and replacing a FRU 103
