1160 Keyboard
For access, remove these FRUs in order:
v “1010 Battery pack” on page 80
v “1030 Optical drive or travel cover” on page 84
v “1110 Palm rest assembly with cables” on page 98
Table 25. Removal steps of keyboard
1
Step Screw (quantity) Color Torque
1 M2 × 5 mm, wafer-head, nylon-coated (1) Black 0.181 Nm
(1.85 kgfcm)
Removing and replacing a FRU 107
