Lenovo ThinkPad T15 Gen 1 User Manual

Features and specifications
Dimensions
• T14 Gen 1 and P14s Gen 1:
– Width: 329 mm (12.95 inches)
– Depth: 227 mm (8.94 inches)
– Thickness: 18.4 mm (0.72 inches)
• T15 Gen 1 and P15s Gen 1:
– Width: 365.8 mm (14.4 inches)
– Depth: 248 mm (9.76 inches)
– Thickness: 19.5 mm (0.77 inches)
Maximum heat output
(depending on the model)
• 45 W (154 Btu/hr)
• 65 W (222 Btu/hr)
Power source (ac power
adapter)
• Sine-wave input at 50 Hz to 60 Hz
• Input rating of the ac power adapter: 100 V to 240 V ac, 50 Hz to 60 Hz
Microprocessor
To view the microprocessor information of your computer, right-click the Start button
and then click System.
Memory
• Double data rate 4 (DDR4) small outline dual in-line memory module (SODIMM)*
• Double data rate 4 (DDR4) on-board memory module
Note: Depending on the system configuration, memory speeds might vary.
Storage device
• M.2 solid-state drive*
• Hybrid solid-state drive (with Intel Optane™ memory) (for selected Intel models)
Display
• Brightness control
• Color display with Thin Film Transistor (TFT) technology
• Color display with In-Plane Switching (IPS) or Twisted Nematic (TN) technology
• Display size:
– T14 Gen 1 and P14s Gen 1: 355.6 mm (14 inches)
– T15 Gen 1 and P15s Gen 1: 396.2 mm (15.6 inches)
• Display resolution:
– T14 Gen 1 (for Intel models) and P14s Gen 1: 1366 x 768 pixels, 1920 x 1080
pixels, or 3840 x 2160 pixels
– T14 Gen 1 (for AMD models): 1920 x 1080 pixels
– T15 Gen 1 and P15s Gen 1: 1920 x 1080 pixels or 3840 x 2160 pixels
• Multi-touch technology*
• PrivacyGuard feature*
• Intel Ultra High Definition (UHD) Graphics or discrete graphics (for Intel models)
• AMD integrated graphics (for AMD models)
Chapter 1. Meet your computer 11

Lenovo ThinkPad T15 Gen 1 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black
Housing material	Acrylonitrile butadiene styrene (ABS), Polycarbonate (PC), Polyphenylene sulfide (PPS)
Market positioning	Business
Numeric keypad	Yes
Keyboard layout	QWERTY
Pointing device	ThinkPad UltraNav
Keyboard language	Nordic
Display diagonal	15.6 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display brightness	250 cd/m²
Native aspect ratio	16:9
Operating system architecture	64-bit
Processor cache	6 MB
Processor cores	4
Processor family	Intel® Core™ i5
Configurable TDP-up	25 W
Processor frequency	1.6 GHz
Configurable TDP-down	10 W
Processor manufacturer	Intel
Processor boost frequency	4.2 GHz
Configurable TDP-up frequency	2.1 GHz
Configurable TDP-down frequency	0.8 GHz
Motherboard chipset	Intel SoC
Memory slots	1x SO-DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Memory form factor	On-board + SO-DIMM
Internal memory type	DDR4-SDRAM
Maximum internal memory	40 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
Storage media	SSD
SSD form factor	M.2
Total storage capacity	256 GB
Compatible memory cards	MicroSD (TransFlash)
Number of SSDs installed	1
Battery capacity	57 Wh
Battery life (max)	15.26 h
AC adapter power	65 W
Discrete graphics card model	Not available
On-board graphics card model	Intel® UHD Graphics
Cable lock slot type	Kensington
Password protection type	HDD, Power on, Supervisor
Trusted Platform Module (TPM) version	2.0
Audio chip	Realtek ALC3287
Audio system	Dolby Audio
Speaker power	2 W
Number of built-in speakers	2
Privacy type	Privacy shutter
Front camera HD type	HD
Front camera resolution	1280 x 720 pixels
WWAN	Installed
Bluetooth version	5.2
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN controller model	Intel Wi-Fi 6 AX201
Ethernet LAN data rates	100, 1000 Mbit/s
Sustainability certificates	ENERGY STAR, EPEAT Gold, RoHS, TCO
HDMI version	1.4b
USB 2.0 ports quantity	0

Weight and Dimensions

Depth	248 mm
Width	365.8 mm
Height	19.1 mm
Weight	1810 g
