Lenovo ThinkPad T15 Gen 1 User Manual

Use advanced options
Note: The items in the graphical user interface (GUI) might change without notice.
1. Open the Start menu, and then click Settings ➙ Update & security ➙ Recovery.
2. In the Advanced startup section, click Restart now ➙ Troubleshoot ➙ Advanced options.
3. Select a preferred option, and then follow the on-screen instructions.
Windows automatic recovery
Note: Ensure that your computer is connected to ac power during the recovery process.
The Windows recovery environment on your computer operates independently from the Windows 10
operating system. It enables you to recover or repair the operating system even if the Windows 10 operating
system fails to start.
After two consecutive failed boot attempts, the Windows recovery environment starts automatically. Then
you can choose repair and recovery options by following the on-screen instructions.
Create and use a recovery USB device
It is recommended that you create a recovery USB drive as early as possible as a backup for the Windows
recovery programs. With the recovery USB drive, you can troubleshoot and fix the problems even if the
preinstalled Windows recovery programs are damaged. If you did not create a recovery USB drive as a
precautionary measure, you can contact Lenovo Customer Support Center and purchase one from Lenovo.
For a list of the Lenovo Support phone numbers for your country or region, go to:
https://pcsupport.lenovo.com/supportphonelist
Create a recovery USB drive
Attention: The creation process deletes anything stored on the USB drive. To avoid data loss, make a
backup copy of all the data that you want to keep.
1. Ensure that your computer is connected to ac power.
2. Prepare a USB drive with at least 16 GB of storage capacity. The actual USB capacity required depends
on the size of the recovery image.
3. Connect the prepared USB drive to the computer.
4. Type recovery in the search box. Then, click Create a recovery drive.
5. Click Yes in the User Account Control window to allow the Recovery Media Creator program to start.
6. In the Recovery Drive window, follow the on-screen instructions to create a recovery USB drive.
Use the recovery USB drive
1. Ensure that your computer is connected to ac power.
2. Connect the recovery USB drive to the computer.
3. Turn on or restart the computer. When the logo screen is displayed, press F12. The Boot Menu window
opens.
4. Select the recovery USB drive as the boot device.
5. Click Troubleshoot to display optional recovery solutions.
6. Select a recovery solution as desired. Then, follow the on-screen instructions to complete the process.
Chapter 6. Configure advanced settings 51

Lenovo ThinkPad T15 Gen 1 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black
Housing material	Acrylonitrile butadiene styrene (ABS), Polycarbonate (PC), Polyphenylene sulfide (PPS)
Market positioning	Business
Numeric keypad	Yes
Keyboard layout	QWERTY
Pointing device	ThinkPad UltraNav
Keyboard language	Nordic
Display diagonal	15.6 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display brightness	250 cd/m²
Native aspect ratio	16:9
Operating system architecture	64-bit
Processor cache	6 MB
Processor cores	4
Processor family	Intel® Core™ i5
Configurable TDP-up	25 W
Processor frequency	1.6 GHz
Configurable TDP-down	10 W
Processor manufacturer	Intel
Processor boost frequency	4.2 GHz
Configurable TDP-up frequency	2.1 GHz
Configurable TDP-down frequency	0.8 GHz
Motherboard chipset	Intel SoC
Memory slots	1x SO-DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Memory form factor	On-board + SO-DIMM
Internal memory type	DDR4-SDRAM
Maximum internal memory	40 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
Storage media	SSD
SSD form factor	M.2
Total storage capacity	256 GB
Compatible memory cards	MicroSD (TransFlash)
Number of SSDs installed	1
Battery capacity	57 Wh
Battery life (max)	15.26 h
AC adapter power	65 W
Discrete graphics card model	Not available
On-board graphics card model	Intel® UHD Graphics
Cable lock slot type	Kensington
Password protection type	HDD, Power on, Supervisor
Trusted Platform Module (TPM) version	2.0
Audio chip	Realtek ALC3287
Audio system	Dolby Audio
Speaker power	2 W
Number of built-in speakers	2
Privacy type	Privacy shutter
Front camera HD type	HD
Front camera resolution	1280 x 720 pixels
WWAN	Installed
Bluetooth version	5.2
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN controller model	Intel Wi-Fi 6 AX201
Ethernet LAN data rates	100, 1000 Mbit/s
Sustainability certificates	ENERGY STAR, EPEAT Gold, RoHS, TCO
HDMI version	1.4b
USB 2.0 ports quantity	0

Weight and Dimensions

Depth	248 mm
Width	365.8 mm
Height	19.1 mm
Weight	1810 g
