Lenovo ThinkPad T15 Gen 1 User Manual

Appendix A. Important safety information
Safety notices
This information can help you safely use your computer. Follow and retain all information included with your
computer. The information in this document does not alter the terms of your purchase agreement or the
Limited Warranty. For more information, see "Warranty Information" in the Safety and Warranty Guide that
comes with your computer.
Customer safety is important. Our products are developed to be safe and effective. However, personal
computers are electronic devices. Power cords, power adapters, and other features can create potential
safety risks that can result in physical injury or property damage, especially if misused. To reduce these risks,
follow the instructions included with your product, observe all warnings on the product and in the operating
instructions, and review the information included in this document carefully. By carefully following the
information contained in this document and provided with your product, you can help protect yourself from
hazards and create a safer computer work environment.
Note: This information includes references to power adapters and batteries. In addition, some products
(such as speakers and monitors) ship with external power adapters. If you have such a product, this
information applies to your product. In addition, computer products contain a coin-sized internal battery that
provides power to the system clock even when the computer is unplugged, so the battery safety information
applies to all computer products.
Important information about using your computer
Ensure that you follow the important tips given here to get the most use and enjoyment out of your computer.
Failure to do so might lead to discomfort or injury, or cause the computer to fail.
Protect yourself from the heat that your computer generates.
When your computer is turned on or the battery is charging, the base,
the palm rest, and some other parts may become hot. The
temperature they reach depends on the amount of system activity and
the level of charge in the battery.
Extended contact with your body, even through clothing, could cause
discomfort or even a skin burn.
• Avoid keeping your hands, your lap, or any other part of your body
in contact with a hot section of the computer for any extended
time.
• Periodically take your hands away from the keyboard by lifting your
hands from the palm rest.
© Copyright Lenovo 2020 87

Lenovo ThinkPad T15 Gen 1 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black
Housing material	Acrylonitrile butadiene styrene (ABS), Polycarbonate (PC), Polyphenylene sulfide (PPS)
Market positioning	Business
Numeric keypad	Yes
Keyboard layout	QWERTY
Pointing device	ThinkPad UltraNav
Keyboard language	Nordic
Display diagonal	15.6 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display brightness	250 cd/m²
Native aspect ratio	16:9
Operating system architecture	64-bit
Processor cache	6 MB
Processor cores	4
Processor family	Intel® Core™ i5
Configurable TDP-up	25 W
Processor frequency	1.6 GHz
Configurable TDP-down	10 W
Processor manufacturer	Intel
Processor boost frequency	4.2 GHz
Configurable TDP-up frequency	2.1 GHz
Configurable TDP-down frequency	0.8 GHz
Motherboard chipset	Intel SoC
Memory slots	1x SO-DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Memory form factor	On-board + SO-DIMM
Internal memory type	DDR4-SDRAM
Maximum internal memory	40 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
Storage media	SSD
SSD form factor	M.2
Total storage capacity	256 GB
Compatible memory cards	MicroSD (TransFlash)
Number of SSDs installed	1
Battery capacity	57 Wh
Battery life (max)	15.26 h
AC adapter power	65 W
Discrete graphics card model	Not available
On-board graphics card model	Intel® UHD Graphics
Cable lock slot type	Kensington
Password protection type	HDD, Power on, Supervisor
Trusted Platform Module (TPM) version	2.0
Audio chip	Realtek ALC3287
Audio system	Dolby Audio
Speaker power	2 W
Number of built-in speakers	2
Privacy type	Privacy shutter
Front camera HD type	HD
Front camera resolution	1280 x 720 pixels
WWAN	Installed
Bluetooth version	5.2
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN controller model	Intel Wi-Fi 6 AX201
Ethernet LAN data rates	100, 1000 Mbit/s
Sustainability certificates	ENERGY STAR, EPEAT Gold, RoHS, TCO
HDMI version	1.4b
USB 2.0 ports quantity	0

Weight and Dimensions

Depth	248 mm
Width	365.8 mm
Height	19.1 mm
Weight	1810 g

Summary

Meet Your Computer: Hardware Overview

Computer Layout: Front, Base, Sides, Bottom, Rear

Details physical components and ports on the computer's front, base, sides, bottom, and rear.

Computer Specifications and Ports

Lists dimensions, heat, memory, storage, display, and connector details.

USB Transfer Rate Information

Explains data transfer rates for various USB connections on the device.

Getting Started with Windows 10

Windows Setup and User Interface

Guides on initial Windows 10 setup, user accounts, and the UI elements.

Connecting to Networks

Instructions for connecting to wired Ethernet, Wi-Fi, and cellular networks.

Using Lenovo Vantage and System Tools

Information on using Lenovo Vantage for system updates and Quick Clean for maintenance.

Computer Interaction and Keyboard Shortcuts

Covers interacting with the computer and using keyboard shortcuts for efficiency.

System Configuration and Security

Managing Power and Battery Life

Guides on checking battery status, charging, maximizing life, and power plans.

Data Transfer and Wireless Connectivity

Covers file sharing via Bluetooth, NFC, and using storage cards.

Password Protection and Biometric Security

Details password types (UEFI BIOS) and biometric features like fingerprint and face ID.

UEFI BIOS and System Recovery

Covers UEFI BIOS settings, startup sequence, system date/time, and recovery options.

Accessories and Maintenance

Docking Stations and External Displays

Explains connecting docking stations and multiple external displays.

CRU Replacement Procedures

Step-by-step guides for replacing customer-replaceable units (CRUs).

Support, Safety, and Compliance

Help Resources and Troubleshooting

Provides FAQs, error message solutions, and support contact information.

Important Safety Information

Crucial safety notices regarding heat, electrical hazards, and handling.

Accessibility and Ergonomic Guidance

Information on accessibility features and proper computer usage posture.

Compliance, Environmental, and Notices

Details Linux OS info, compliance statements, environmental data, and legal notices.
