Lenovo ThinkPad T15 Gen 1 User Manual

Front view
Note: The following illustration is based on ThinkPad Basic Docking Station. The ThinkPad Pro Docking
Station and ThinkPad Ultra Docking Station might look slightly different.
1. System lock
Use the system lock in the following ways:
• Locked position
: The latch is locked, and you cannot attach or detach your
computer.
• Unlocked position
: The latch is unlocked, and you can attach or detach
your computer.
• Removal position
: You can remove the system lock from the system-lock
slot.
Note: The ThinkPad Basic Docking Station does not ship with a system lock
installed. You can contact Lenovo sales to purchase a system lock with the option
part number 4XE0Q56388.
2. Key lock indicator This indicator turns on when the system lock key is in the locked position.
3. Docking status indicator
This indicator turns on when your computer is successfully connected to the
docking station.
4. Power button
Press the power button to turn on or turn off the computer attached to the
docking station.
5. Guide post
Use the guide post to help you position your computer properly when you attach
the computer to the docking station.
6. Docking-station connector Connect the computer to the docking station.
7. Hooks
Hold and secure the computer to the docking station.
8. Latch
Slide the latch to attach or detach the computer.
38 T14 Gen 1, T15 Gen 1, P14s Gen 1, and P15s Gen 1 User Guide

Lenovo ThinkPad T15 Gen 1 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black
Housing material	Acrylonitrile butadiene styrene (ABS), Polycarbonate (PC), Polyphenylene sulfide (PPS)
Market positioning	Business
Numeric keypad	Yes
Keyboard layout	QWERTY
Pointing device	ThinkPad UltraNav
Keyboard language	Nordic
Display diagonal	15.6 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display brightness	250 cd/m²
Native aspect ratio	16:9
Operating system architecture	64-bit
Processor cache	6 MB
Processor cores	4
Processor family	Intel® Core™ i5
Configurable TDP-up	25 W
Processor frequency	1.6 GHz
Configurable TDP-down	10 W
Processor manufacturer	Intel
Processor boost frequency	4.2 GHz
Configurable TDP-up frequency	2.1 GHz
Configurable TDP-down frequency	0.8 GHz
Motherboard chipset	Intel SoC
Memory slots	1x SO-DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Memory form factor	On-board + SO-DIMM
Internal memory type	DDR4-SDRAM
Maximum internal memory	40 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
Storage media	SSD
SSD form factor	M.2
Total storage capacity	256 GB
Compatible memory cards	MicroSD (TransFlash)
Number of SSDs installed	1
Battery capacity	57 Wh
Battery life (max)	15.26 h
AC adapter power	65 W
Discrete graphics card model	Not available
On-board graphics card model	Intel® UHD Graphics
Cable lock slot type	Kensington
Password protection type	HDD, Power on, Supervisor
Trusted Platform Module (TPM) version	2.0
Audio chip	Realtek ALC3287
Audio system	Dolby Audio
Speaker power	2 W
Number of built-in speakers	2
Privacy type	Privacy shutter
Front camera HD type	HD
Front camera resolution	1280 x 720 pixels
WWAN	Installed
Bluetooth version	5.2
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN controller model	Intel Wi-Fi 6 AX201
Ethernet LAN data rates	100, 1000 Mbit/s
Sustainability certificates	ENERGY STAR, EPEAT Gold, RoHS, TCO
HDMI version	1.4b
USB 2.0 ports quantity	0

Weight and Dimensions

Depth	248 mm
Width	365.8 mm
Height	19.1 mm
Weight	1810 g
