Note: The cellular service is provided by authorized mobile service carriers in some countries or regions.
You must have a cellular plan from a service carrier to connect to the cellular network.
To establish a cellular connection:
1. Turn off the computer.
2. Insert a straightened paper clip into the hole in the tray
1 . The tray ejects. Then, slide the tray out of the
computer. Install a nano-SIM card into the tray
2 with the metal contacts facing downward. Insert the
tray into the nano-SIM-card slot until you hear a click
3 .
3. Turn on the computer.
4. Click the network icon in the Windows notification area, and then select the cellular network icon
from
the list.
5. Provide required information if needed.
Use Lenovo Vantage
The preinstalled Lenovo Vantage is a customized one-stop solution to help you maintain your computer with
automated updates and fixes, configure hardware settings, and get personalized support.
Access Lenovo Vantage
Open the Start menu and click Lenovo Vantage. You also can type Lenovo Vantage in the search box.
To download the latest version of Lenovo Vantage, go to Microsoft Store and search by the app name.
Key features
Lenovo Vantage enables you to:
Know the device status easily and customize device settings.
Download and install UEFI BIOS, firmware, and driver updates to keep your computer up-to-date.
Monitor your computer health, and secure your computer against outside threats.
Look up warranty status (online).
Access User Guide and helpful articles.
Notes:
The available features vary depending on the computer model.
Lenovo Vantage makes periodic updates of the features to keep improving your experience with your
computer. The description of features might be different from that on your actual user interface.
18
T14 Gen 1, T15 Gen 1, P14s Gen 1, and P15s Gen 1 User Guide

Table of Contents

Other manuals for Lenovo ThinkPad T15 Gen 1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lenovo ThinkPad T15 Gen 1 and is the answer not in the manual?

Lenovo ThinkPad T15 Gen 1 Specifications

General IconGeneral
Form factorClamshell
Product typeLaptop
Product colorBlack
Housing materialAcrylonitrile butadiene styrene (ABS), Polycarbonate (PC), Polyphenylene sulfide (PPS)
Market positioningBusiness
Numeric keypadYes
Keyboard layoutQWERTY
Pointing deviceThinkPad UltraNav
Keyboard languageNordic
Display diagonal15.6 \
Anti-glare screenAlways gives an optimal view, even in direct sunlight.
Display brightness250 cd/m²
Native aspect ratio16:9
Operating system architecture64-bit
Processor cache6 MB
Processor cores4
Processor familyIntel® Core™ i5
Configurable TDP-up25 W
Processor frequency1.6 GHz
Configurable TDP-down10 W
Processor manufacturerIntel
Processor boost frequency4.2 GHz
Configurable TDP-up frequency2.1 GHz
Configurable TDP-down frequency0.8 GHz
Motherboard chipsetIntel SoC
Memory slots1x SO-DIMM
Internal memory8 GB
Memory channelsDual-channel
Memory form factorOn-board + SO-DIMM
Internal memory typeDDR4-SDRAM
Maximum internal memory40 GB
SSD capacityThe Solid State Drive's storage capacity in Gigabytes.
Storage mediaSSD
SSD form factorM.2
Total storage capacity256 GB
Compatible memory cardsMicroSD (TransFlash)
Number of SSDs installed1
Battery capacity57 Wh
Battery life (max)15.26 h
AC adapter power65 W
Discrete graphics card modelNot available
On-board graphics card modelIntel® UHD Graphics
Cable lock slot typeKensington
Password protection typeHDD, Power on, Supervisor
Trusted Platform Module (TPM) version2.0
Audio chipRealtek ALC3287
Audio systemDolby Audio
Speaker power2 W
Number of built-in speakers2
Privacy typePrivacy shutter
Front camera HD typeHD
Front camera resolution1280 x 720 pixels
WWANInstalled
Bluetooth version5.2
Top Wi-Fi standardWi-Fi 6 (802.11ax)
WLAN controller modelIntel Wi-Fi 6 AX201
Ethernet LAN data rates100, 1000 Mbit/s
Sustainability certificatesENERGY STAR, EPEAT Gold, RoHS, TCO
HDMI version1.4b
USB 2.0 ports quantity0
Weight and Dimensions IconWeight and Dimensions
Depth248 mm
Width365.8 mm
Height19.1 mm
Weight1810 g
