Lenovo ThinkPad USB 3.0 Dock User Manual

Chapter1.AbouttheThinkPadUSB3.0Dock
Thischaptercontainstheproductdescription,locationsofcontrols,andsystemrequirementsforthe
ThinkPad
®
USB3.0Dock(hereaftercalledthedock).
Productdescription
Thedockisaportableexpansionmodulethatenablesyoutoeasilyconnectyournotebookcomputertothe
Ethernetandmultipledevices,suchasaheadset,amicrophone,andUniversalSerialBus(USB)devices.It
simultaneouslysupportsuptotwoexternalmonitorswiththemaximumresolutionof2048x1152pixels,and
providesveUSB3.0connectorsforhigherbandwidthandbetterperformance.Thedockalsosupports
GigabitEthernetspeedwhenyouconnectittonetworks.
YoucansetupyourworkareabyconnectingyournotebookcomputertothedockwiththeprovidedUSB
3.0cable,connectingmultipledevicestothedock,andsettingthedockonyournotebookcomputer;then,
youarereadytousethemultipledeviceseachtimeyouconnectyournotebookcomputertothedock.
Youroptionpackageincludesthefollowing:
•ThinkPadUSB3.0Dock
•Poweradapter
•Powercord
•USB3.0cable
•DVI-ItoVGAadapter
•Warrantyposter
•SoftwareandUserGuideCD
Contactyourplaceofpurchaseifanyitemismissingordamaged.Besuretoretainyourproofofpurchase
andpackingmaterial.Theymightberequiredtoreceivewarrantyservice.
©CopyrightLenovo2012
1

Lenovo ThinkPad USB 3.0 Dock Specifications

General

Microphone in	Yes
DVI-I ports quantity	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	0
Connectivity technology	Wired
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	5
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Product color	Black
Card reader integrated	No
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	91 mm
Width	48 mm
Height	126 mm
Weight	299 g
