Lenze E84AVSC User Manual

from Firmware V06.00 - DMS 1.1 EN - 11/2011 L 41
8400 StateLine C | Operating instructions
Commissioning
Adapting the most important parameters to the drive task
C00114
C00118
C00434/1
C00435/1
Digital inputs (DIx): Polarity
The polarity of each digital input of the device can be inverted via this bit field.
Setting range (min. hex value | max. hex value) Lenze setting
0x0000 0xFFFF 0x0000
Decimal: 0
Binary: 00000000.00000000
The keypad displays the setting as bit string (bit 0 is at
the rightmost position):
Value is bit-coded: (; =bit set) Info
Bit 0  DI1 inverted Inversion of digital input 1
Bit 1  DI2 inverted Inversion of digital input 2
Bit 2  DI3 inverted Inversion of digital input 3
Bit 3  DI4 inverted Inversion of digital input 4
Bit 4 ... 14  Reserved
Bit 15  RFR inverted Inversion of digital input RFR (controller enable)
DIx: polarity
C00114
EDIT
00000000
DI1
DI2
DI3
DI4
00000000.
RFR
Digital outputs (DOx): Polarity
The polarity of each digital output of the device can be inverted via this bit field.
Setting range (min. hex value | max. hex value) Lenze setting
0x00 0xFF 0x00
Decimal: 0
Binary: 00000000
The keypad displays the setting as bit string (bit 0 is at
the rightmost position):
Value is bit-coded: (; =bit set) Info
Bit 0  Relay inverted Relay inversion
Bit 1  DO1 inverted Inversion of digital output 1
Bit 2 ... 7  Reserved
DOx: polarity
C00118
EDIT
0000
Relay
0000
DO1
Analog voltage output (O1U): Gain
Setting range (min. value | unit | max. value) Lenze setting
-199.99 % 199.99 100.00 %
Analog voltage output (O1U): Offset
Setting range (min. value | unit | max. value) Lenze setting
-199.99 % 199.99 0.00 %
