Lenze E84AVSC User Manual

from Firmware V06.00 - DMS 1.1 EN - 11/2011 L 43
8400 StateLine C | Operating instructions
Commissioning
Adapting the most important parameters to the drive task
C00018
C00021
C00019
C00036
C00106
Switching frequency
Selection of the pulse width modulated switching frequency transferred from the inverter to the motor
• Select between an ideal setting for the drive which provides smooth running, and an optimal setting with regard
to the inverter which keeps its losses to a minimum (min. Pv).
• Both possibilities offer fixed and variable switching frequencies.
• When a variable switching frequency is selected, the switching frequency may change as a function of the load
and rotational frequency.
Selection list (Lenze setting printed in bold)
1 4 kHz var./drive-optimised 15 2 kHz constant/min. Pv
2 8 kHz var./drive-optimised 16 4 kHz constant/min. Pv
3 16 kHz var./drive-optimised 17 8 kHz constant/min. Pv
5 2 kHz constant/drive-optimised 18 16 kHz constant/min. Pv
6 4 kHz constant/drive-optimised 21 8 kHz var./drive-opt./4 kHz min
7 8 kHz constant/drive-optimised 22 16 kHz var./drive-opt./4 kHz min
8 16 kHz constant/drive-optimised 23 16 kHz var./drive-opt./8 kHz min
11 4 kHz var./min. Pv 31 8 kHz var./min. Pv/4 kHz min
12 8 kHz var./min. Pv 32 16 kHz var./min. Pv/4 kHz min
13 16 kHz var./min. Pv 33 16 kHz var./min. Pv/8 kHz min
Slip compensation
Slip compensation for V/f characteristic control and sensorless vector control
• A higher slip compensation results in a higher increase in frequency and voltage when the machine is under load.
• After the motor to be used has been selected from the »Engineer« motor catalogue, the suitable value can be
entered automatically. An automatic detection via the motor parameter identification is possible as well.
Setting range (min. value | unit | max. value) Lenze setting
-100.00 % 100.00 2.67 %
Auto-DCB: Threshold
Setpoint speed threshold for automatic DC injection braking
• For speed setpoints with values below the thresholds a DC current is injected or the motor is not supplied with
current, depending on the setting.
Setting range (min. value | unit | max. value) Lenze setting
0 rpm 60000 3rpm
DC braking: Current
Current value in [%] for DC-injection braking
•100% ≡ Imax in motor mode (C00022
)
Setting range (min. value | unit | max. value) Lenze setting
0.00 % 200.00 50.00 %
Auto-DCB: Hold time
Hold time of the automatic DC injection brake
• The DC injection brake is applied for the time set here if the value falls below the speed setpoint set in C00019
.
Setting range (min. value | unit | max. value) Lenze setting
0.000 s 999.000 0.500 s
