Lenze i700 Series User Manual

Technical data
Rated data
Axis modules
4
l
38
EDS700ACBA EN 5.1
4.2.4 Axis modules
Basics of the rated data
Mains Vol ta
g
e Volta
g
e ran
g
e Fre
q
uenc
y
ran
g
e
Voltage
U
DC
[V]
Voltage
range
U
DC
[V]
Frequency
range
f [Hz]
2/PE DC 565 455 − 0 % ... 620 + 0 % −
2/PE DC 675 540 − 0 % ... 746 + 0 % −
Input data
Voltage Frequency current [A]
Number of
phases
[V] [Hz] up to +40 °C

up to +55 °C

E70ACMxx0054xx1xxx 565/675 DC 5.0/4.9 3.1/3.1 2
E70ACMxx0104xx1xxx 565/675 DC 9.3/9.2 5.8/5.8 2
E70ACMxx0204xx1xxx 565/675 DC 18.7/18.5 11.7/11.6 2
E70ACMxx0324xx1xxx 565/675 DC 29.8/29.7 18.6/18.6 2
E70ACMxx0484xx1xxx 565/675 DC 44.6/44.5 27.9/27.9 2
E70ACMxx0644xx1xxx 565/675 DC 59.2/59.1 37.0/37.0 2
E70ACMxx0054xx2xxx 565/675 DC 9.3/9.2 5.8/5.8 2
E70ACMxx0104xx2xxx 565/675 DC 18.7/18.5 11.7/11.6 2
E70ACMxx0204xx2xxx 565/675 DC 37.0/36.9 23.1/23.0 2
E70ACMxx0324xx2xxx 565/675 DC 59.2/59.1 37.0/37.0 2
 Temperature in the control cabinet

Lenze i700 Series Specifications

General

Product Category	Inverter
Series	i700
Protection Class	IP20
Frequency Range	0 to 599 Hz
Control Type	Vector control
Communication Interfaces	EtherCAT, CANopen
Safety	STO (Safe Torque Off), SS1 (Safe Stop 1)
Overload Capacity	200% for 3 seconds
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overtemperature
Ambient Temperature	-10°C to +50°C
Voltage	400 V
Input Voltage	3-phase AC
