Mechanical installation

Assembly in push−through technique (thermal separation)

EDS700ACBA EN 5.1

i700P011 d

a e c c1 c2 c3 d1 d2 d3 d4 d5 j11 j21

[A] [mm]

E70ACPSD0304x 30

340 50 25 25

−

10 10 390 15 35 90 70

E70ACMxD0054xx1xxx 5

E70ACMxD0104xx1xxx 10

E70ACMxD0204xx1xxx 20

E70ACMxD0054xx2xxx 2*5

E70ACMxD0104xx2xxx 2*10

E70ACPSD0604x 60

85 50

E70ACMxD0324xx1xxx 32

E70ACMxD0484xx1xxx 48

E70ACMxD0644xx1xxx 64

E70ACMxD0204xx2xxx 2*20

E70ACMxD0324xx2xxx 2*32
