Lewmar V1-6 Windlass ref 65001201 iss.8 | 19
7.2-2
7.3-1
7.3-4
7.3-3
7.3-2

 Gypsy only (optional manual recovery Kit No.66840054)
 Gypsy/drum (optional manual recovery Kit No.66840056)
 Sport versions: These units have no manual recovery.
1. Engage fall safe pawl.
2. Place a Lewmar winch handle into gypsy drive cap/drum top nut and rotate anti-clockwise by half a turn.
3. Remove handle and place into the bi-square in the cap and rotate clockwise.
4. Once anchor is retrieved, ensure it is adequately secured to an independent strong point.
Gypsy/drum versions
These units use emergency manual recovery attachment 66840056. See document 66300003 RevA for fitting and
operating instructions.
 WARNING! Isolate the wind-
lass using circuit breaker/
isolator.
7.3 V1-3 manual recovery
