Installing a 530-sheet drawer
8
Installing and removing options
Installing a 530-sheet drawer
Once you have selected a location and positioned an optional drawer, you are ready to position the printer.
Lift the printer by the recessed handholds on both sides, and place it on the optional drawer.
CAUTION: The printer weighs 29 kg (66 lb), and requires at least two people to lift it safely.
To position the printer on the optional drawer:
1 Align the posts, slots, and connector on the drawer with the underside of the printer.
2 Lower the printer into place. Make sure it is seated securely on the drawer.
Slot
Post
Connector
