Identifying the media path
56
Clearing jams
Identifying the media path
The following illustration shows the path that media travels through the printer. The path varies depending on the input
source (tray 1 or tray 2).
Tray2
JAM-A
JAM-B
JAM-C
Tray1
JAM-A
