A-8
PREPARATION
PREPARATION
ATTACHING THE TV TO A DESK
Desk
Stand
■ Image shown may differ from your TV.
The TV must be attached to desk so it cannot
be pulled in a forward/backward direction,
potentially causing injury or damaging the
product.
WARNING
►To prevent TV from falling over, the TV
should be securely attached to the floor/wall
per installation instructions. Tipping, shaking,
or rocking the machine may cause injury.
1-Screw
( provided as parts of the product)
SWIVEL STAND
■ This feature is not available for all models.
■ Image shown may differ from your TV.
After installing the TV, you can adjust the TV set
manually to the left or right direction by 20
degrees to suit your viewing position.
Protective Bracket
Bolt
Secure the power cable with the Protective Bracket
and the bolt as shown. It will help prevent the power
cable from being removed by accident.
HOW TO SECURE THE
POWER CABLE
(Only 26/32/37/42LD3***)
(Only 26/32/37/42LD3****)
POSITIONING YOUR DISPLAY
■ Image shown may differ from your TV.
■ Adjust the position of the panel in various ways
for maximum comfort.
• Tilt range
(Only 22LD3***)
►
Screw: M5 x L (*L: Table depth + 8~10 mm)
ex) Table depth: 15mm, Screw: M5 x 25
4-Screws
(not provided as parts of the product)
Stand
Desk
To Next Page
