PREPARATION
PREPARATION
30
WOOFER INSTALLATION: WHEN USING THE WALL
MOUNT (For 32/42/47/55LE4600)
1
Carefully place the TV screen side down
on a cushioned surface to protect the
screen from damage.
2
Remove the screws from the TV.
3
Detach the STAND REAR COVER and
STAND from TV.
4
Detach the WOOFER from the stand.
5
Assemble the WOOFER with the TV.
Turn the PEM nut for the woofer using a
flathead driver and install the 2 screws as
shown.
When installing the woofer in the TV, make
sure that the power cord is not twisted,
bent or pinched.
To Next Page
