Control Board TP TipsControl Board TP Tips
EXTERNAL TRIGGER: (VS_DA) can be used as an
External Trigger for your scope when locking onto
External
Trigger
for
your
scope
when
locking
onto
the Y-Scan or the Z-Drive signal.
VS_DA
AUTO
Auto Gen (Internal Automatic Generator)
Short these two pins together to generate patterns on the
fPlTt
AUTO
GEN
May 2011 50PV450 Plasma
109
screen
f
or a
P
ane
l
T
es
t
.
If patterns do not appear, try removing the LVDS Cable.
