INVISIBLE SPEAKER SYSTEM SECTIONINVISIBLE SPEAKER SYSTEM SECTION
The
50PV450
contains the Invisible Speaker system
Invisible Speaker System Overview (Full Range Speakers)Invisible Speaker System Overview (Full Range Speakers)
p/n: EAB62028901
The
50PV450
contains
the
Invisible
Speaker
system
.
The Full Range Speakers point downward, so there are no front viewable speaker grills or air ports.
Installed Bottom View
Anti Rattle
Pad
Anti Rattle
Pad
Reading across
speaker wires,
8.2 ohm.
Remove two screws
from the bottom
Rear View Front View
Speaker
May 2011 50PV450 Plasma
15 5
Speaker
Connection
