Main Board Layout and IdentificationMain Board Layout and Identification
P701
LVDS
IC1
Microprocessor
Video
p
rocesso
r
P301 to
SMPS
p
P704
to Ft IR
USB 1
Silicon
P801
Speakers
HDMI 3
Silicon
Tuner
HDMI 2
May 2011 50PV450 Plasma
136
HDMI 1
