Power Supply Circuit LayoutPower Supply Circuit Layout
P811
SMPS p/n: EAY62171101
VS Source
VS VR901
To Y- SUS
Fuse F801
160.1V Stby
390V Run
4Amp/250V
VA Source
V
A VR501
4Amp/250V
17V Source
Fuse F302
160.1V Stby
390V Run
2.5Amp/250V
Bridge
STBY 5V,
5V Source
PFC
C
ircuit
RL103
Bridge
Rectifiers
C
To MAIN
P813
RL103
Main Fuse
F101
P701
n/a
May 2011 50PV450 Plasma
46
10Amp/250V
AC Input
SC 101
