EXTERNAL EQUIPMENT SETUP
EXTERNAL EQUIPMENT SETUP
44
OTHER A/V SOURCE SETUP
AV IN 2
VIDEO
AUDIO
L(MONO)
R
H/P
N 4
USB IN 1 USB IN 2
L R
VIDEO
Camcorder
Video Game Set
1. How to connect
1
Connect the AUDIO/VIDEO jacks
between TV and external equipment.
Match the jack colors
.
(
Video = yellow, Audio Left = white, and
Audio Right = red
)
2. How to use
Select the AV1 or AV2 input source on
the TV using the INPUT button on the
r
emote control.
Operate the corresponding external
equipment.
1
