Lightware DVIDL-OPT-TX200 User Manual


10. Appendix DVIDL-OPT series – User's Manual 34
10
Appendix
ç 
ç 
ç 
ç 
ç 

General
Compliance ......................................................................................... CE
EMC (Emission) ............................................................. EN 55032:2015
EMC (Immunity) ............................................................. EN 55035:2017
Safety .......................................................................... EN 60065 Class II
 .......................................................................................3 years
Cooling.........................................................................................Passive
Operating temperature ............................... 
Operating humidity ..................................10% to 90%, non-condensing
Power
Power supply .....................................................External power adaptor
Power adaptor ................. 
Power connector ........................ Locking DC connector (2.35 mm pin)
 ............................................................
 ...............................................................

Enclosure
Rack mountable ...................................... Yes, with rack shelf (1U high)
Material .................................................................................. 1 mm steel
Dimensions in mm .... 
Dimensions in inch .........................................
 ................................................................ 726 g (1.601 lbs)
 ................................................................ 721 g (1.589 lbs)
Video Ports
Connector type ................................................................... 29-pole, DVI-I
Standard .......................................................................................DVI 1.0
Color depth .............................................. 
Color format ......................................................................................RGB
Colorspace conversion ....................................................................... No
Maximum data rates ................. 
Video delay .................................................................................. 0 frame
Resolution ....................................................................up to 4096x2400
 .......................................................... TMDS Reclocking
 ....................... yes, Advanced EDID Management
 .......yes, 60 factory preset, 39 user programmable
 .................................... 256 byte extended EDID v1.3
HDCP compliant.................................................................................. No
Optical Ports
Connector type ................................
Fiber type .................................................... 
Laser wavelengths ............... 
 .......................................................... Class 3R
 ................................-6.25 dBm (worst case)
 .............................-14.25 dBm (worst case)
Optical loss budget .................................................8 dBm (worst case)
Transmission distance .............. 


................................... 
 ..... 
USB port ........................................................
Power connector ............. 

OM1 OM2 OM3 OM4
   
1080p@60Hz
24 bpp
250 m 600 m 1200 m 2500 m
1080p@60Hz
36 bpp
150 m 400 m 800 m 1300 m
4096x2048@30Hz
24 bpp
Not
supported
350 m 700 m 1100 m





Lightware DVIDL-OPT-TX200 Specifications

General

Brand	Lightware
Model	DVIDL-OPT-TX200
Category	Extender
Language	English
