GB-6
Preparation Connections Initial Setup Using the Features EPG (Electronic
Programme Guide)
Using the DVD Features Hints and Tips, Specification
and Safety Warnings
Front View and Controls
Item Description
1 POWER LED
Illuminates green when the TV is turned on. Illuminates red when the TV is in standby
mode. The LED will illuminate green when the timer programming has started in the
standby mode.
2 IR (Infrared Receiver)
Receives IR signals from the remote control.
Do not put anything near the sensor, as its function may be affected.
3 USB port
Allows the insertion of a USB storage device to play video, audio, photo and text files
by using the USB extension cable provided. (DVD Mode)
4 SD/MMC/MS port
Allows the insertion of a SD/MMC/MS card to play video, audio, photo and text files.
(DVD mode)
5 /
Press to skip to the beginning of the previous / next chapter or track. (DVD mode)
6
Press to stop playback. (DVD mode)
7
Press to start playback or pause. (DVD mode)
8
Press to eject disc. (DVD mode)
9 SOURCE
Press to select among different input signal sources:
DTV / TV / Scart / AV / DVD / YPbPr / PC / HDMI1 / HDMI2.
10 MENU Displays the OSD (on screen display) menu.
11 CH +/- Press to select a channel or select a sub-menu from the OSD menu.
12 VOL +/-
Adjusts the volume.
Press to select and adjust a setting in the OSD menu.
13
Switches the TV on from standby.
Switches the TV back to standby.
9
10
12
13
11
USB
SD/MMC MS
3
4
6
7
8
5
1 2
L26DVDB20_IB_final110210_running change4.indd 6 10/02/2011 3:43 PM
