Lombardini 3LD 450 User Manual

BOOK CODE
1-5302-556
MODEL No.
50839
DATE OF ISSUE
01-94
REVIEW 02
DATE
30-11-2001
APPROVAL
TECO/ATL AUTHOR
30
TYPE OF SEALANT
LOCTITE 270
LOCTITE 270
LOCTITE 270
LOCTITE 270
LOCTITE 270
LOCTITE 270
LOCTITE 270
LOCTITE 270
LOCTITE 270
LOCTITE 270
LOCTITE 270
LOCTITE 270
LOCTITE 270
Clutch bearing bell and embedded hexagonal-head screws
Control pin threading
Coupling nipple for oil filter cartridge
Stud bolt for clamping on engine head
Stud bolt for clamping on main bearing flywheel side
Stud bolt for clamping on distributor port side
Stud bolt on engine bell
Clamping screw for pin regulator
Clamping screw for baffle on air conveyor
Stud bolt for clamping on engine flange bell
Rocker arm fulcrum pin for injection pump control
Bracket clamping screw on side plates
Stud bolt for clamping at feeding pump
POSITION
USE OF DOPE FOR 3LD 450 - 3LD 510 - 3LD 451/S - 3LD 510/S
POSITION
Bearing on port or bell
Regulating pin threading
Stud bolt for clamping on engine head
Stud bolt for clamping on main bearing on flywheel side
Stud bolt for clamping on distribution side
Lock screw for rocker arm pin
Clamping screw for regulating pin
Industrial port
Stud bolt for clamping on feeding pump
USE OF DOPE FOR 4LD 640 - 4LD705 - 4LD 820
LOCTITE 270
LOCTITE 270
LOCTITE 270
LOCTITE 270
LOCTITE 270
LOCTITE 270
LOCTITE 270
DOW CORNING Q3 - 7091SILICONE
LOCTITE 270
TYPE OF SEALANT
USE OF SEALANT
