DATE
30-11-2001
TECO/ATL AUTHOR
BOOK CODE
1-5302-556
MODEL No.
50839
DATE OF ISSUE
01-94
REVIEW 02
APPROVAL
31
DRIVING TORQUES FOR STANDARD SCREWS
NAME
Dia. per pitch
(mm)
R
≥≥
≥≥
≥ 800 N/mm²
R
≥≥
≥≥
≥ 1000 N/mm²
R
≥≥
≥≥
≥ 1200 N/mm2
Nm Kgm Nm Kgm Nm Kgm
4x0.70
5x0.80
6x1.00
7x1.00
8x1.25
9x1.25
10x1.50
13x1.75
14x2.00
16x2.00
18x2.50
20x2.50
22x2.50
24x3.00
0.62
1.22
2.08
3.40
5.10
6.55
9.05
15.30
23.30
35.40
44.40
61.80
74.90
96.00
0.52
1.01
1.73
2.84
4.25
5.45
7.54
12.80
19.40
29.50
37.00
51.50
62.40
80.00
3.6
7
12
19.8
29.6
38
52.5
89
135
205
257
358
435
557
5.1
9.9
17
27.8
41.6
53.4
73.8
125
190
289
362
504
611
784
6
11.9
20.4
33
50
64.2
88.7
150
228
347
435
605
734
940
0.37
0.72
1.23
2.02
3.02
3.88
5.36
9.09
13.80
21.00
26.30
36.60
44.40
56.90
XV
DRIVING TORQUES
