DATE
30-11-2001
TECO/ATL AUTHOR
BOOK CODE
1-5302-556
MODEL No.
50839
DATE OF ISSUE
01-94
REVIEW 02
APPROVAL
5
SAE 5W/30
SAE 10W/40
SAE 15W/40
SAE 15W/30
-20
-10
+10
+20
+30
0
-13 -4
5
14
23 32 41
86
50 59
68
77
SAE 40
°C
°F
SAE 30
SAE 20W/20
RATING
SAE 10W
CAPACITIES IN LITERS
Standard fuel tank
3LD450, 3LD510, 3LD451/S, 3LD510/S = 5.3
4LD 640, 4LD705, 4 LD 820 = 7.2
Standard oil sump:
3LD450, 3LD510, 3LD451/S, 3LD510/S =1.75
4LD640, 4LD705, 4LD 820 = 2.60
Air filter oil bowl = 0.3
For special filters, tanks and oil sumps, please
follow LOMBARDINI instructions.
INTERVALS (HOURS)
OPERATION DETAIL
10 50 125 250 500 1000 2500 5000
AIR FILTER (OIL-BATH) (*)
CLEANING HEAD AND CYLINDER FINS (*)
FUEL TANK
INJECTORS
AIR FILTER OIL
CHECK LEVEL SUMP OIL
BATTERY LIQUID
FUEL HOSE COUPLING FASTENING
VALVE AND ROCKER ARM CLEARANCE
INJECTOR SETTING
AIR FILTER(**) (***)
CHANGE SUMP (***)
OIL FILTER CARTRIDGE
FUEL FILTER CARTRIDGE
OVERHAUL PARTIAL (****)
GENERAL
First replacement.
(*) In particular running conditions even every day.
(**) In particularly dusty environments every 4-5 hours.
(***) See prescribed oil.
(****) It includes the check of cylinders, segments, guides, valve seat springs and grindings, head and cylinder
descaling, injection pump and injector checks.
RECOMMENDED OIL
AGIP DIESEL SIGMA S SAE 30-40 MIL-L-2104 C
ESSOLUBE D3 specification, MIL-L-2104 D and
UNIFARM specification MIL-L-2104 C. For
Countries in which AGIP and ESSO products
are not available, the prescribed oil is API
SERVICE CD for diesel engines or oil which
should be in conformity with the MIL -L-2104 C
and MIL -L-2104D military specifications.
MAINTENANCE -PRESCRIBED OIL - REFUELLINGS
III
