Lombardini LDW 502 User Manual

- 102 -
FOCS Workshop Manual_cod. 1.5302.351_7° ed_ rev. 06
7107-1460-127
7107-1460-030
7271-1460-024
7107-1460-053
7107-1460-029
7107-1460-027
7107-1460-031
7107-1460-028
7107-1460-047
7107-1460-048
7107-1460-049
7107-1460-051
7107-1460-056
7107-1460-074
13
Injection pumps delivery balancing
instrument
Precombustion chamber extractor
Injection pump static injection advance
tester(old type)
Sheet metal for insertion of main bearings in
the crankcase
Ring nut wrench for fastening pump/injector
pumping element
Precombustion chamber wrench
Precombustion chamber adjusting rod
Coupling for static injection advance control
and setting of old-type injection pumps
injector
Device for mounting valve guide gasket,
intake and exhaust side
Valve lowering device for injection advance
control
Timing belt tightening tool
Crankshaft clamping tool
Tool for injection advance control and setting
of injector for pump/injector unit: se.no.
6590-272
Tool for injection advance control and setting
of injector for pump/injector unit: se.no.
6590-285, 6590-307, 6590-290
SPECIAL TOOLS DESCIPTION Part N°.
SPECIAL TOOLS

Lombardini LDW 502 Specifications

General

Engine Type	Diesel, 4-stroke
Number of Cylinders	2
Fuel System	Indirect injection
Starting System	Electric start
Lubrication System	Forced lubrication with gear pump
Bore x Stroke	72 mm x 62 mm
Cooling System	Air-cooled
Displacement	505 cm³ (30.8 cu in)
