REG. CODE
1-5302-351
MODEL N°
50563
DATE OF ISSUE
04.90
REVISION 04
DATE
15.11.99
ENDORSED
COMPILER TECO/ATI
28
DRIVING TORQUES FOR STANDARD SCREWS
DENOMINATION
Diameter x pitch
(mm)
R
³³
³³
³ 800 N/mm²
R
³³
³³
³ 1000 N/mm²
R
³³
³³
³ 1200 N/mm²
4x0.70
5x0.80
6x1.00
7x1.00
8x1.25
9x1.25
10x1.50
13x1.75
14x2.00
16x2.00
18x2.50
20x2.50
22x2.50
24x3.00
0.62
1.22
2.08
3.40
5.10
6.55
9.05
15.30
23.30
35.40
44.40
61.80
74.90
96.00
0.52
1.01
1.73
2.84
4.25
5.45
7.54
12.80
19.40
29.50
37.00
51.50
62.40
80.00
3.6
7
12
19.8
29.6
38
52.5
89
135
205
257
358
435
557
5.1
9.9
17
27.8
41.6
53.4
73.8
125
190
289
362
504
611
784
6
11.9
20.4
33
50
64.2
88.7
150
228
347
435
605
734
940
0.37
0.72
1.23
2.02
3.02
3.88
5.36
9.09
13.80
21.00
26.30
36.60
44.40
56.90
SEALANT and THREAD LOCK LOCATIONS/ DETAILS
LOCATION DETAIL SEALANT / THREAD LOCK
(LOCTITE BRAND)
Valve / Rocker Cover 12mm Crankcase Vent Tube 638
Oil Filter Nipple M20x1.5 Hollow Nipple 601
Camshaft Bearing Retainer Bolts M6 270
Timing Belt Idler Stud to Crankcase M10 601
Crankcase M12x1.5 Plug 242
Cylinder Head 18mm Plug 510
Cylinder Head M6x1.0 Stud 601
Crankcase and Cylinder Head Welch Plugs (30mm) 510
GENERALI
Nm Kgm Nm Kgm Nm Kgm
