LS tractor XR4150 User Manual

4 -29
(*) 1 : Front axle, 2 : Rear axle
Axle No.
(*)
Tires
Standard air
pressure (kg/cm2)
Load rating
per tire (kg)
Max. mass
per axle (kg)
Maximum
mass (kg)
1
7-16 4PR
76 A6
1.8 (180 KPa, 26 psi) 405 (893 lb) 810 (1786 lb)
2915
(6426 lb)
2
11.2-24 8PR
115 A6
2.4 (240 KPa, 35 psi) 1235 (2723 lb) 2105 (4641 lb)
1
8-16 4PR
82 A6
1.6 (160 KPa, 23 psi) 475 (1047 lb) 950 (2094 lb)
3008
(6631 lb)
2
12.4-24 8PR
120 A6
1.6 (160 KPa, 23 psi) 1445 (3186 lb) 2105 (4641 lb)
1
8-18 6PR
93 A6
1.6 (160 KPa, 23 psi) 660 (1455 lb) 1320 (2910 lb)
3008
(6631 lb)
2
13.6-24 8PR
124 A6
2.2 (220 KPa, 31 psi) 1615 (3560 lb) 2105 (4641 lb)
1
9.5-16 6PR
96 A6
2.2 (220 KPa, 31 psi) 725 (1598 lb) 1320 (2910 lb)
3008
(6631 lb)
2
13.6-24 8PR
124 A6
2.2 (220 KPa, 31 psi) 1615 (3560 lb) 2105 (4641 lb)
1
8.3-20 6PR
96 A6
2.4 (240 KPa, 35 psi)
710 (1565 lb) 1320 (2910 lb)
3008
(6631 lb)
2
12.4-28 6PR
116 A6
1.6 (160 KPa, 23 psi)
1275 (2811 lb) 2105 (4641 lb)
1
260/70R16
109 A8
2.4 (240 KPa, 34 psi)
1030 (2271 lb)
1320 (2910 lb)
3008
(6631 lb)
2
360/70R24
122 A8
1.9 (190 KPa, 27 psi)
1500 (3307 lb)
2105 (4641 lb)
1
250/75R16
120 G
4.5 (450 KPa, 64 psi)
1400 (3086 lb)
1320 (2910 lb)
3008
(6631 lb)
2
340/80R24
135 D
3.2 (320 KPa, 45 psi)
2180 (4806 lb)
2105 (4641 lb)
1
400/60-15.5
132 A8 FLOAT
3.5 (350 KPa, 50 psi)
2000 (4409 lb)
1320 (2910 lb)
3008
(6631 lb)
2
550/60-22.5
152 B FLOAT
2.8 (280
KPa, 40 psi)
3550 (7826 lb)
2105 (4641 lb)
 For safe operation and secure the reliability of the driveline, use only approved tire combination and
manage the specified tire air pressure regularly as below table. If using an unapproved tire
combination or unsuitable tire air pressure, it may cause failure of the front/rear axle and reduce the
reliability of the driveline.
(5) Tires and Load capacity
▶ Do not exceed the maximum permissible mass(Total/Front/Rear) declared by
manufacturer. Overloaded operation may invalidate the warranty. For further
information, refer to the chapter 4-5-(4) in this manual.
▶ If the front/rear tires have enough load capacity, the permissible mass on each
axle can be restricted by the maximum permissible mass of the front/rear axle.
Caution
