LS tractor XR4150 User Manual

5 -48
① Fuse check and replacement
 How to change the fuse.
1. Remove the fuse box cover.
2. Check each fuse and remove the damaged one.
3. Replace it with a new one of the same capacity
as the damaged fuse.
 Chassis fuse box is installed under the front
console and cabin fuse box is on the left cabin
pillar.
 The capacity and function of each fuse is
described on the fuse box cover.
< Cabin fuse box (Cabin type) >
(2) Fuse & Main fuse
Cabin fuse
box cover
< Chassis fuse box >
▶If the same function fuse is damaged repeatedly, contact your authorized local
dealer for check instead of using a substitute such as wire or aluminum foil.
▶If using the substitute instead of the rated capacity fuse, it may cause a fire which
results in damage of the tractor or personal injury.
Caution
Chassis fuse box
