6 -8
6-6. System diagram
Heater evaporator
Fan motor
Evaporator core
Heater core
Hot water
Control panel
Engine
Compressor
Fan
Radiator
Condenser
w/receiver drier
Quick coupler
Expansion valve
Heater lose
Cooler hose
Electric line
