26 ENGLISH
Vertical vise
WARNING: The workpiece must be secured
the vise during all operations. If the workpiece is
not properly secured against the fence the material
may move during the cutting operation causing
possible damage to the blade, causing the material
to be thrown and loss of control resulting in serious
The vertical vise can be installed in two positions each
on the left and right side of the base. Insert the vise rod
into one of the holes in the base.
Position the vise arm according to the thickness and
shape of the workpiece and secure the vise arm by
tightening the clamping screw. If the clamping screw
contacts the carriage, install it on the opposite side of
vise arm. Make sure that no part of the tool contacts the
vise when lowering the handle all the way. If some part
contacts the vise, re-position the vise.
the turn base. Position the workpiece at the desired
vise knob.
Fig.42: 1. Holes 2. Vise rod 3. Vise arm 4. Clamping
screw 5. Vise knob
Horizontal vise
Optional accessory
WARNING: Always rotate the nut holder
clockwise until the workpiece is properly secured.
If the workpiece is not properly, secured the material
may move during the cutting operation causing pos-
sible damage to the circular saw blade, causing the
material to be thrown and loss of control resulting in
WARNING: When cutting a thin workpiece,
such as base boards, against the fence, always
use the horizontal vise.
CAUTION: When cutting the workpiece of the
thickness 20 mm or thinner, make sure to use a
spacer block to secure the workpiece.
The horizontal vise can be installed either on the left or
on the right side of the base. When performing 22.5° or
greater miter cuts, install the horizontal vise on the side
opposite to the direction in which the turn base is to be
turned.
is released, and rapidly moves in and out. To grip the
workpiece, push the vise knob forward until the vise
clockwise. Then turn the vise knob clockwise to secure
the workpiece.
Fig.43: 1. Vise plate 2. Nut holder 3. Vise knob
NOTE: The maximum width of workpiece which can
be secured by the horizontal vise is 68 mm.
Sub base
WARNING: Always support a long workpiece
so it is level with the top surface of the turn base
for an accurate cut and to prevent dangerous loss
of tool control. Proper workpiece support will help
avoid blade pinch and possible kickback which may
WARNING: Before the cutting operation,
always be sure that the sub bases are secured by
the screws.
To hold long workpieces horizontally, sub bases are
provided on both sides of the tool. Loosen the screws
and extend the sub bases to the appropriate length for
holding the workpiece. Then tighten the screws.
Fig.44: 1. Sub base 2. Screw
fences.
Fig.45: 1. Guide fence 2. Sub base
OPERATION
This tool is intended to cut wood products. With appro-
priate Makita genuine saw blades, following materials
can also be sawed :
— Aluminum products
Refer to our website or contact your local Makita dealer
for the correct circular saw blades to be used for the
material to be cut.
WARNING: Make sure the circular saw blade
is not contacting the workpiece, etc. before the
switch is turned on. Turning the tool on with the
circular saw blade in contact with the workpiece may
WARNING: After a cutting operation, do not
raise the circular saw blade until it has come to a
complete stop. The raising of a coasting blade may
workpiece.
WARNING: Do not perform any adjustment
such as turning grip, levers, stopper pin on the
tool while the circular saw blade is rotating.
CAUTION: Do not release the saw head
uncontrolled from the fully down position.
Uncontrolled saw head may hit you and it will result in
To Next Page
