Example:
In the case of cutting 52/38° type crown molding for
• Tilt and secure bevel angle setting to 33.9° LEFT.
RIGHT.
• Lay crown molding with its broad back (hidden)
surface down on the turn base with its CEILING
CONTACT EDGE against the guide fence on the
saw.
the LEFT side of the circular saw blade after the
cut has been made.
In the case of right bevel cut
(a) (b) (c) (d)
12
1. Inside corner 2. Outside corner
Table (A)
– Molding
position
in the
Bevel angle Miter angle
52/38°
type
45° type 52/38°
type
45° type
For
inside
corner
(a) Right
33.9°
Right
30°
Right
31.6°
Right
35.3°
(b) Left
31.6°
Left
35.3°
For
outside
corner
(c)
(d) Right
31.6°
Right
35.3°
Table (B)
– Molding
position in
Molding
edge against
guide fence
Finished
piece
For inside
corner
(a) Wall contact
edge should
be against
guide fence.
Finished
piece will be
on the Right
side of blade.
(b) Ceiling
contact edge
should be
against guide
fence.
For outside
corner
(c) Finished
piece will be
on the Left
side of blade.
(d) Wall contact
edge should
be against
guide fence.
Example:
In the case of cutting 52/38° type crown molding for
• Tilt and secure bevel angle setting to 33.9° RIGHT.
RIGHT.
• Lay crown molding with its broad back (hidden)
surface down on the turn base with its WALL
CONTACT EDGE against the guide fence on the
saw.
the RIGHT side of the circular saw blade after the
cut has been made.
Cutting aluminum extrusion
Fig.51: 1. Vise 2. Spacer block 3. Guide fence
4. Aluminum extrusion 5. Spacer block
When securing aluminum extrusions, use spacer blocks
deformation of the aluminum. Use a cutting lubricant
when cutting the aluminum extrusion to prevent build-up
of the aluminum material on the circular saw blade.
WARNING: Never attempt to cut thick or
round aluminum extrusions. Thick or round alumi-
may loosen during the cutting operation which may
Groove cutting
WARNING: Do not attempt to perform this
type of cut by using a wider type blade or dado
blade. Attempting to make a groove cut with a wider
blade or dado blade could lead to unexpected cutting
results and kickback which may result in serious
WARNING: Be sure to return the stopper arm
to the original position when performing other
than groove cutting. Attempting to make cuts with
the stopper arm in the incorrect position could lead to
unexpected cutting results and kickback which may
For a dado type cut, perform as follows:
1.
limit the cutting depth of the circular saw blade. Refer to
the section for stopper arm.
2. -
lar saw blade, cut parallel grooves across the width of
the workpiece using a slide (push) cut.
Fig.52: 1. Cut grooves with blade
3. Remove the workpiece material between the
grooves with a chisel.
