INTAKE/EXHAUSTSYSTEM
EXHAUSTPIPES
Removing,installingexhaustpipes
Additionaljobs
–Removing,installingtheturbocharger,see173
(1)Coverplate
(2)Coverplate
(3)Coverplate
(4)Exhaustpipe
Technicaldata
Mountingbolt,exhaustpipe..................................M10x40-HWF................................Initialtorque22Nm
Mountingbolt,exhaustpipe..................................M10x40-HWF..................................2ndtightening90°
Mountingbolt,exhaustpipe..................................M10x40-HWF.................................Finaltightening10°
Mountingnuts,turbocharger..................................M10...................................................................60Nm
Importantinformation
WARNING
Componentdamageduetoincorrectlytightenedscrew/boltconnections
•Ifimpactwrenchesareused,thesemayonlybeusedforpretighteningtomax.50%ofthe
speciedtighteningtorque
•Finaltighteningmustalwaysbeperformedmanuallyusingatorquewrench
Note
Therightexhaustpipeisremovedandinstalledinexactlythesameway
AE63stedition205
