Man D2862 LE221 User Manual

ENGINEELECTRICS
ENGINEWIRINGHARNESS
Removing,installingtheenginewiringharness
Additionaljobs
–Removing,installingthecombinationairlter,see187
–Removing,installingenginecontrolunits,see27
–Removing,installingthecombinationairlterholder,see193
(1)Enginewiringharness
Technicaldata
Electricalconnection,terminal85relay............................................................................................4Nm
Electricalconnection,terminal50relay............................................................................................4Nm
Electricalconnection,B+,alternator................................................................................................15Nm
Importantinformation
CAUTION
Dangerofinjuryonsharp-edgedprojectionsonthecableties
•OnlytightenandcutoffcabletieswiththeCabletiepliers[1]
WARNING
Electricalcabledamageduetoovertightening
•FollowtheoperatinginstructionsfortheCabletiepliers[1]
AE63stedition25
