Maintenance
9.4 Description of the maintenance work
Lattice extension operating instructions 3 112 441 en 9 - 5
GMK 4100/4100-L/5095
11.01.2008
9.4 Description of the maintenance work
9.4.1 Lubricate pin
Grease, spare
parts and tools
The following table holds only for GMK 5095:
–Brush.
H
Lubricate the pins additionally after every high-pressure cleaning in order to
avoid corrosion.
At the swing-
away lattice
Prerequisites
– The truck crane is secured against unauthorised use;
à Maintenance
manua
for the supplied truck crane.
or:
– The swing-away lattice has been removed;
à p. 3 - 10.
Lubricating pins:
Lubricate all pins:
– Pins for the connections with folded swing-away lattice;
à p. 3 - 37.
– Pins for the connections on the left and right-hand side of the main boom
head;
à p. 3 - 49.
– Pins for the section 1 and section 2 connections;
à p. 3 - 59.
– Pins on the deflection sheave;
à p. 3 - 64.
– Spring latch on the hose drum;
à p. 3 - 33.
s
On the boom
extension
Lubricate all pins of the boom extension:
M 1
Grease
1)
Designation
per DIN 51502
Specification
Classification
GROVE
part no.
1)
Grease KP - L2K DIN 51825 00554201
1)
à Lubricant list and lubricant use Maintenance manual GMK 5095
Designation Quantity GROVE part no.
No spare parts
